Sale!

ZOOM Recorder Controller R-16

Name: ZOOM Recorder Controller R-16
SKU: 9829
Availability: InStock

Original price was: ₹61,520.00.Current price is: ₹46,500.00.

Specs

RECORDER

TRACK COUNT	16 (mono)
MAXIMUM NUMBER OF SIMULTANEOUS RECORDING TRACKS	8
MAXIMUM NUMBER OF SIMULTANEOUS PLAYBACK TRACKS	16 audio + metronome
RECORDING FORMAT	44.1 kHz, 16/24-bit WAV format
MAXIMUM RECORDING TIME	200 minutes/1 GB (mono tracks)
PROJECTS	1000
MARKERS	100/project
LOCATOR	Hours/minutes/seconds/milliseconds and bars/beats/ticks
FILE EDITING	Divide
TRACK PARAMETERS	3-band equalizer, pan (balance), effect send ×2, invert
STEREO LINK	Tracks 1 / 2 – 15 / 16 selectable
OTHER FUNCTIONS	Punch-in/out (manual, auto), Bounce, A-B repeat, Undo/Redo

EFFECTS

ALGORITHMS	8 (CLEAN, DISTORTION, ACO/BASS SIM, BASS, MIC, DUAL MIC, STEREO, MASTERING)
PATCHES	330 insert, 60 send-return
EFFECTS MODULES	7 insert, 2 send

TUNER

TYPE	Chromatic, guitar, bass, open A/D/E/G, D modal

METRONOME

TONES	5
BEAT	No accent, 1 / 4 – 8 / 4, 6 / 8
TEMPO	40.0 – 250.0 BPM

HARDWARE

MIXER FADERS	9 (mono x 8, master x 1)
RECORDING MEDIA	SD card (16MB – 2 GB), SDHC card (4 – 32 GB)
ANALOG-DIGITAL CONVERSION	96 kHz 24-bit delta-sigma ADC
DIGITAL-ANALOG CONVERSION	96 kHz 24-bit delta-sigma DAC
DISPLAY	20-digit 2-line custom LCD (with backlight)
LEVEL METERS	4-segment LED
INPUTS	Input 1-8 Type: XLR/TRS combo jacksInput impedance: (Balanced input) 1KΩ balanced (2 hot), (Unbalanced input) 50 KΩ unbalanced (1 with Hi-Z input impedance 470 KΩ (Hi-Z on), 5 / 6 with phantom power)Phantom Power: +48VInput level: -50 dBm < continuous < +4 dBm
	Built-in stereo microphones Type: Omnidirectional condenser microphonesGain: -50 dBm < continuous < +4 dBm
OUTPUTS	Output \| Type: TRS phone (balanced)
	Phones\| Standard stereo phone jack 20 mW x 2 (32 Ω load)

USB

MINI-B TYPE (USB 2.0)	Operation as audio interface/ control surface and mass storage

USB AUDIO INTERFACE

NUMBER OF RECORDING CHANNELS	8
NUMBER OF PLAYBACK CHANNELS	2
BIT RATE	24
SAMPLING FREQUENCY	44.1, 48, 88.2, 96 kHz
COMPATIBILITY	Windows® 10 / 11, Intel® Core i3 or faster, RAM 1 GB or more (*USB 2.0 compatible port, Intel chipsets recommended)
	macOS 10.14 ~ 13, Intel® Core Duo 1.83 GHz or faster and RAM 1 GB or more (*USB 2.0 compatible port, Intel chipsets recommended)

POWER

AC ADAPTER	DC 5V 1A (Zoom AD-14)
BATTERIES	6 AA batteries (4.5-hour continuous operation time with backlight on and phantom power off)

OTHER

DIMENSIONS	376 mm (W) × 237.1 mm (D) × 52.2 mm (H)
WEIGHT	1.3 kg

Add to Wishlist

Add to wishlist

Spread the love

Description
Reviews (0)

R16 Features

16-track playback, 8-track simultaneous recording
Built-in stereo condenser microphones
Records directly to SD and SDHC cards up to 32 GB for up to 100 track hours
Records 16/24-bit, 44.1 kHz mono and stereo WAV files
Eight mic/line level inputs on XLR/TRS combo connectors
Input 1 can also be used for Hi-Z instrument-level signals such as electric guitar or bass
+48V phantom power
Dual balanced ¼” TRS output jacks
Headphone output with dedicated volume control
Built-in metronome and chromatic tuner
135 send-return and insert DSP effects, including amp/preamp models and mastering algorithms
User editing of effects parameters, with 390 patch memories for storage
Independent level, pan and EQ for each track
Internal track bouncing and mixdown of multitrack to stereo
Flexible overdubbing and both manual and automatic punch-in/out
Loop A/B playback with user-defined start/stop points
Up to 100 marks per recording
Invert track phase function
Divide file editing
Backlit LCD with contrast control for easy viewing in low-light environments
8-in/2-out USB audio interface for Macintosh/Windows computers
High-definition 24-bit/96 kHz playback capability with DAW software
Control Surface functionality (Mackie Control emulation)
Full mixing and transport controls for Cubase, Logic, Ableton Live, and other DAWs
Two R16s can be synchronized via USB for 32 tracks of playback and 16 tracks of simultaneous recording
USB bus power
SD card reader function
Runs on 6 AA batteries, with alkaline battery life of more than 4.5 hours
AC adapter included

Reviews

There are no reviews yet.

Be the first to review “ZOOM Recorder Controller R-16”

You must be logged in to post a review.

Category: HANDY RECORDER

NUMBER OF INPUT CHANNELS	8 (XY mic capsule, 1-4, A, B)
NUMBER OF OUTPUT CHANNELS	2 (stereo headphone and stereo line)

MIC IN	ZOOM mic connector
INPUT 1-4	XLR jacks (2: HOT)
INPUT A/B	XLR/TRS combo jacks (XLR: 2 hot, TRS: TIP hot)
USB	USB Micro-B(audio interface, mass storage and Guitar Lab connection functions)Note: Use a USB cable that supports data transfer.Operation using USB bus power is possible.
REMOTE	ZOOM BTA-1 or other dedicated wireless adapter
LINE OUT	3.5 mm stereo mini
PHONE OUT	3.5 mm stereo mini

RECORDING MEDIA	Cards that support SD/SDHC/SDXC specifications
FORMATS	WAV: 44.1/48/96 kHz, 16/24-bit, mono/stereoMP3: 128, 192, 320 kbps
MAXIMUM SIMULTANEOUS RECORDINGTRACKS	12 (MIC IN, backup recording, 1-4, A, B, and LR)

MULTITRACK MODE	44.1/48/96 kHz, 16/24-bit, 12-in/2-out
STEREO MIX MODE	44.1/48 kHz, 24-bit, 2-in/2-out

TUNER	Chromatic/Guitar/Bass/Open A/Open D/Open E/Open G/DADGAD
BUILT-IN SPEAKER	400 mW 8Ω mono speaker
DISPLAY	2.4″ (320×240) full-color touchscreen LCD
POWER	4 AA batteries (alkaline, NiMH or lithium)AC adapter (ZOOM AD-17): DC 5 V/1AUSB bus power
	Using XY mic, 44.1 kHz/24-bit (stereo × 1): about 10:00
	The above values are approximate.
	Continuous battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions.
EXTERNAL DIMENSIONS H8	116.4 mm (W) × 163.3 mm (D) × 48.6 mm (H)
XYH-6	78.9 mm (W) × 60.2 mm (D) × 45.2 mm (H)
WEIGHT H8	354 g XYH-6: 130 g
	Note: When using a USB cable designed for recharging, audio interface, SD card reader and Guitar Lab connection functions cannot be used.
