Product Showcase
Genelec 8320A SAM Two way Monitor System
₹117,000.00
| Power Configuration | Bi-amped |
|---|---|
| Powered | Yes |
| Quantity | Single |
| LF Driver Size | 4″ |
| LF Driver Type | Cone |
| HF Driver Size | 0.75″ |
| HF Driver Type | Dome |
| LF Driver Power Amp | 50W |
| HF Driver Power Amp | 50W |
| Total Power | 100W |
| Frequency Response | 66Hz-20kHz (±1.5dB) |
| Crossover Frequency | 2.9kHz |
| Maximum Peak SPL | 107 dB SPL @ 1m |
| Input Types | 1 x XLR |
| Enclosure Type | Ported |
| Height | 9.5″ (with Iso-Pod Stand); 9.06″ (without Iso-Pod Stand) |
| Width | 6″ |
| Depth | 5.625″ |
| Weight | 7 lbs. |
Available on backorder
- Genelec 8320A SAM: Two-way Monitor System Compact and adaptable nearfield monitor for project studios, workstations, and surround components
- Smart Active Monitor (SAM) offers highly accurate monitoring.
- Low distortion. The 4-inch woofer and 3/4-inch metal-dome tweeter provide excellent clarity.
- Separate 50W bass and treble amplifiers provide constant power distribution.
- The Minimum Diffraction Enclosure (MDE) provides concentrated nearfield sound.
Genelec 8320A SAM Overview
The Genelec 8320A is a single SAM-Series, 2-way active studio monitor designed to provide accurate mix referencing with software control capabilities for audio engineers, musicians, and producers in project studios, small control rooms, edit suites, or mobile setups. It has 100W of Class-D amplification that powers a 4″ woofer and a 3/4″ tweeter, with a frequency response of 55 Hz to 23 kHz.
A unique waveguide improves imaging, while the bass reflex port broadens the low-frequency response. The die-cast aluminum casing is designed to reduce diffraction and reflection. An XLR 3-pin jack provides a connection to a balanced analog source. Built-in signal overload protection improves reliability and protects the speaker. GLM (Genelec Loudspeaker Manager) software and the GLM User Kit (sold separately) allow for detailed frequency changes and automated calibration. A configurable power-saving mode allows for automated power up/down via a signal-sensing circuit.
The 8320A has several mounting options, including an Iso-Pod isolation stand and threaded holes that work with mic stands and other wall/ceiling brackets.
Genelec 8320A SAM Two-way Monitor Features:
- 4″ woofer and 3/4″ tweeter.
- 50W LF and HF amplifiers.
- Frequency response: -6 dB from 55 to 23 kHz and ±1.5 dB from 66 to 20 kHz.
- The proprietary waveguide uses DCW (Directivity Control Waveguide) technology to enhance imaging and expand the listening area.
- The bass reflex port offers a prolonged low-frequency response.
- Allows for automated calibration via software control.
- The low-diffraction aluminum enclosure uses MDE (Minimum Diffraction Enclosure) technology.
- Analog input is balanced and connected via an XLR 3-pin connection.
- ISS (Intelligent Signal Sensing) offers an automated power-saving mode.
- Mounting options include Iso-Pod and threaded holes for mic stands and wall/ceiling brackets.
- Includes an Iso-Pod isolation stand for vibration decoupling.
- The Directivity Control Waveguide (DCW) improves dimensional imaging.
- The high-performance reflex port design provides longer lows.
- High audio output and low distortion provide exceptional clarity.
- Offers versatile mounting options, including a unique Iso-Pod stand.
- Protected by Genelec’s ISS power management technology.
