    BOSS KATANA-Artist MKII Guitar Amplifier

    74,505.00

    Specifications:

    • Rated Power Output:
      • 100 W
    • Nominal Input Level:
      • INPUT: -10 dBu (1 M ohm)
      • AUX IN: -10 dBu (20 k ohms)
      • RETURN IN: -10 dBu (100 k ohm)
    • Speaker:
      • 30 cm (12 inches) x 1

    Controls:

    • Power Controls:
      • POWER switch
      • MASTER knob
      • PRESENCE knob
      • SOLO knob
      • GLOBAL EQ button
      • CONTOUR switch (OFF, 1, 2, 3)
      • POWER CONTROL switch (STANDBY, 0.5 W, 50 W, 100 W)
      • CABINET RESONANCE switch (VINTAGE, MODERN, DEEP)
    • Amplifier Controls:
      • AMP TYPE knob (ACOUSTIC, CLEAN, CRUNCH, LEAD, BROWN)
      • VARIATION button
      • GAIN knob
      • VOLUME knob
    • Equalizer Controls:
      • BASS knob
      • MIDDLE knob
      • TREBLE knob
    • Multi Effect Controls:
      • BOOSTER button
      • MOD button
      • FX button
      • DELAY button
      • REVERB button
      • TAP button
      • BOOSTER knob
      • MOD knob
      • FX knob
      • DELAY knob
      • REVERB knob
    • Tone Setting Controls:
      • BANK button
      • CH1 button
      • CH2 button
      • CH3 button
      • CH4 button
      • PANEL button
    • Expand Controls:
      • EXPAND switch (OFF, STEREO, DUAL LINK)

    Indicators:

    • ACOUSTIC
    • CLEAN
    • CRUNCH
    • LEAD
    • BROWN
    • VARIATION
    • BOOSTER
    • MOD
    • FX
    • DELAY
    • REVERB
    • TAP
    • BANK
    • CH1
    • CH2
    • CH3
    • CH4
    • PANEL
    • GLOBAL EQ

    Connectors:

    • Input/Output Connectors:
      • INPUT jack: 1/4-inch phone type
      • POWER AMP IN/DUAL LINK jack: 1/4-inch phone type
      • LINE OUT jack: 1/4-inch phone type
      • SEND jack: 1/4-inch phone type
      • RETURN jack: 1/4-inch phone type
      • SPEAKER OUT 16 ohms A jack: 1/4-inch phone type
      • SPEAKER OUT 16 ohms B jack: 1/4-inch phone type
      • SPEAKER OUT 8 ohms jack: 1/4-inch phone type
      • REC OUT/PHONES jack: Stereo 1/4-inch phone type
      • EXP PEDAL/CTL CH1/CH2 jack: 1/4-inch TRS phone type
      • GA-FC/CTL SOLO jack: 1/4-inch TRS phone type
      • AUX IN jack: Stereo miniature phone type
      • USB port: USB B type
      • MIDI IN connector
      • AC IN jack

    Power:

    • Power Consumption: 77 W

    Accessories:

    • Included:
      • Owner’s Manual
      • Power cord
      • GA-FC sticker
    • Options (Sold Separately):
      • Footswitch: BOSS FS-5L, BOSS FS-6, BOSS FS-7
      • Expression pedal: Roland EV-5, BOSS EV-30, BOSS FV-500L, BOSS FV-500H
      • GA FOOT CONTROLLER (GA-FC, GA-FC EX)
      • Amplifier Stand: BAS-1

    Size and Weight:

    • Dimensions:
      • Width: 630 mm (24-13/16 inches)
      • Depth: 248 mm (9-13/16 inches)
      • Height: 515 mm (20-5/16 inches)
    • Weight: 19 kg (41 lbs 15 oz)
    Add to cart
  • QuickView
    Wishlist
    Compare

    BOSS KATANA-Artist MKII HEAD Guitar Amplifier

    66,400.00

    Specifications:

    • Rated Power Output:
      • 100 W
    • Nominal Input Level:
      • INPUT: -10 dBu (1 M ohm)
      • AUX IN: -10 dBu (20 k ohms)
      • RETURN IN: -10 dBu (100 k ohm)

    Controls:

    • Power Controls:
      • POWER switch
      • MASTER knob
      • PRESENCE knob
      • SOLO knob
      • GLOBAL EQ button
      • CONTOUR switch (OFF, 1, 2, 3)
      • POWER CONTROL switch (STANDBY, 0.5 W, 50 W, 100 W)
      • CABINET RESONANCE switch (VINTAGE, MODERN, DEEP)
    • Amplifier Controls:
      • AMP TYPE knob (ACOUSTIC, CLEAN, CRUNCH, LEAD, BROWN)
      • VARIATION button
      • GAIN knob
      • VOLUME knob
    • Equalizer Controls:
      • BASS knob
      • MIDDLE knob
      • TREBLE knob
    • Multi Effect Controls:
      • BOOSTER button
      • MOD button
      • FX button
      • DELAY button
      • REVERB button
      • TAP button
      • BOOSTER knob
      • MOD knob
      • FX knob
      • DELAY knob
      • REVERB knob
    • Tone Setting Controls:
      • BANK button
      • CH1 button
      • CH2 button
      • CH3 button
      • CH4 button
      • PANEL button
    • Expand Controls:
      • EXPAND switch (OFF, STEREO, DUAL LINK)
    • Air Feel Controls:
      • TYPE switch (REC, BLEND, LIVE)
      • CUSTOM SETTING switch (OFF, M1, M2)

    Indicators:

    • ACOUSTIC
    • CLEAN
    • CRUNCH
    • LEAD
    • BROWN
    • VARIATION
    • BOOSTER
    • MOD
    • FX
    • DELAY
    • REVERB
    • TAP
    • BANK
    • CH1
    • CH2
    • CH3
    • CH4
    • PANEL
    • GLOBAL EQ

    Connectors:

    • Input/Output Connectors:
      • INPUT jack: 1/4-inch phone type
      • POWER AMP IN/DUAL LINK jack: 1/4-inch phone type
      • LINE OUT jack: 1/4-inch phone type
      • SEND jack: 1/4-inch phone type
      • RETURN jack: 1/4-inch phone type
      • SPEAKER OUT 16 ohms A jack: 1/4-inch phone type
      • SPEAKER OUT 16 ohms B jack: 1/4-inch phone type
      • SPEAKER OUT 8 ohms jack: 1/4-inch phone type
      • REC OUT/PHONES jack: Stereo 1/4-inch phone type
      • EXP PEDAL/CTL CH1/CH2 jack: 1/4-inch TRS phone type
      • GA-FC/CTL SOLO/DUAL LINK jack: 1/4-inch TRS phone type
      • AUX IN jack: Stereo miniature phone type
      • USB port: USB B type
      • MIDI IN connector
      • AC IN jack

    Power:

    • Power Consumption: 77 W

    Accessories:

    • Included:
      • Owner’s Manual
      • Power cord
      • GA-FC sticker
    • Options (Sold Separately):
      • Footswitch: FS-5L, FS-6, FS-7
      • Expression pedal: Roland EV-5, BOSS EV-30, FV-500L, FV-500H
      • Foot Controller: GA-FC, GA-FC EX

    Size and Weight:

    • Dimensions:
      • Width: 631 mm (24-27/32 inches)
      • Depth: 246 mm (9-11/16 inches)
      • Height: 296 mm (11-21/32 inches)
    • Weight: 12.4 kg (27 lbs 5.4 oz)
    Add to cart
  • QuickView
    Wishlist
    Compare

    BOSS KATANA-HEAD MKII Guitar Amplifier

    43,883.00

    Specifications:

    • Rated Power Output:
      • 30 W (Using internal speaker)
      • 100 W (Using external speaker)
    • Nominal Input Level:
      • INPUT: -10 dBu (1 M ohm)
      • AUX IN: -10 dBu (20 k ohms)
      • RETURN IN: -10 dBu (100 k ohm)
    • Speaker:
      • 12 cm (5 inches) x 1

    Controls:

    • Power Controls:
      • POWER switch
      • MASTER knob
      • PRESENCE knob
      • POWER CONTROL switch (STANDBY, 0.5 W, 50 W, 100 W)
      • CAB RESONANCE switch (VINTAGE, MODERN, DEEP)
    • Amplifier Controls:
      • VARIATION button
      • AMP TYPE knob (ACOUSTIC, CLEAN, CRUNCH, LEAD, BROWN)
      • GAIN knob
      • VOLUME knob
    • Equalizer Controls:
      • BASS knob
      • MIDDLE knob
      • TREBLE knob
    • Multi Effect Controls:
      • BOOSTER button
      • MOD button
      • FX button
      • DELAY button
      • REVERB button
      • TAP button
      • BOOSTER knob
      • MOD knob
      • FX knob
      • DELAY knob
      • REVERB knob
    • Tone Setting Controls:
      • CH1 button
      • CH2 button
      • CH3 button
      • CH4 button
      • PANEL button
    • Stereo Expand:
      • STEREO EXPAND switch

    Indicators:

    • VARIATION
    • ACOUSTIC
    • CLEAN
    • CRUNCH
    • LEAD
    • BROWN
    • BOOSTER
    • MOD
    • FX
    • DELAY
    • REVERB
    • TAP
    • CH1
    • CH2
    • CH3
    • CH4
    • PANEL

    Connectors:

    • Input/Output Connectors:
      • INPUT jack: 1/4-inch phone type
      • POWER AMP IN jack: 1/4-inch phone type
      • LINE OUT jack: 1/4-inch phone type
      • SEND jack: 1/4-inch phone type
      • RETURN jack: 1/4-inch phone type
      • SPEAKER OUT jack: 1/4-inch phone type (Minimum 8 ohm)
      • REC OUT/PHONES jack: Stereo 1/4-inch phone type
      • EXP PEDAL/CTL CH1/CH2 jack: 1/4-inch TRS phone type
      • GA-FC jack: 1/4-inch TRS phone type
      • AUX IN jack: Stereo miniature phone type
      • USB port: USB B type
      • MIDI IN connector
      • AC IN jack

    Power:

    • Power Consumption: 77 W

    Accessories:

    • Included:
      • Owner’s manual
      • Power cord
      • GA-FC sticker
    • Options (Sold Separately):
      • Footswitch: BOSS FS-5L, BOSS FS-6, BOSS FS-7
      • Expression pedal: Roland EV-5, BOSS EV-30, BOSS FV-500L, BOSS FV-500H
      • GA FOOT CONTROLLER (GA-FC, GA-FC EX)

    Size and Weight:

    • Dimensions:
      • Width: 470 mm (18-9/16 inches)
      • Depth: 228 mm (9 inches)
      • Height: 215 mm (8-1/2 inches)
    • Weight: 8.8 kg (19 lbs 7 oz)
    Add to cart
  • Sale!
    QuickView
    Wishlist
    Compare

    Boss KATANA-MINI Guitar Amplifier

    Original price was: ₹11,954.00.Current price is: ₹10,100.00.
    SPECIFICATION
    Type Solid State
    Number of Channels 1
    Total Power 7W
    Speaker Size 1 x 4″ speaker
    Effects Delay
    EQ 3-band EQ
    Inputs 1 x 1/4″ (instrument), 1 x 1/8″ (aux in)
    Outputs 1 x 1/8″ (headphones/rec out)
    Headphones Yes
    Power Source 9V DC 350mA power supply (sold separately) / 6 x AA batteries
    Height 7.12″
    Width 9.06″
    Depth 4.6″
    Weight 2.6 lbs.
    Add to cart
  • QuickView
    Wishlist
    Compare

    BOSS LMB-3 Bass Limiter/Enhancer

    11,655.00

    Tuning and Signal Features:

    • Nominal Input Level: -20 dBu, which is typical for guitar-level input.
    • Input Impedance: 1 M ohm, suitable for high-impedance instruments like electric guitars and basses.
    • Nominal Output Level: -20 dBu.
    • Output Impedance: 1 k ohm, which is standard for pedals to be connected to amplifiers or other audio gear.
    • Recommended Load Impedance: 10 k ohms or greater, ensuring compatibility with most amplifiers and other equipment.

    Bypass:

    • Buffered Bypass: Ensures that the signal remains intact when the pedal is turned off, preserving sound quality.

    Controls:

    • THSHD Knob: Likely controls the threshold of the compressor, setting the level at which compression begins to take effect.
    • RATIO Knob: Adjusts the compression ratio, controlling how much compression is applied once the threshold is surpassed.
    • ENHANCE Knob: This could adjust the tonal character or presence of the signal, often used to add brightness or “shine.”
    • LEVEL Knob: Sets the output level of the compressed signal, allowing for volume adjustments after compression is applied.
    • Pedal Switch: Used to engage or bypass the effect.

    Power Supply:

    • Battery Options:
      • Carbon-zinc 9V battery (6F22).
      • Alkaline 9V battery (6LR61).
    • AC Adaptor: PSA series (sold separately).
    • Current Draw:
      • 25 mA, which is relatively low, meaning the pedal consumes little power.
    • Expected Battery Life:
      • Carbon-zinc: Approx. 5 hours of continuous use.
      • Alkaline: Approx. 10.5 hours of continuous use.

    Indicators:

    • CHECK Indicator: Shows when the battery is low or needs to be replaced. It can also be used to verify the pedal’s status.

    Connectors:

    • INPUT Jack: 1/4-inch phone type for connecting instruments or line-level sources.
    • OUTPUT Jack: 1/4-inch phone type for sending the processed signal to an amplifier or next device.
    • DC IN Jack: For connecting an external power source (AC Adaptor, PSA series).

    Accessories:

    • Included: Leaflet with safety and usage instructions, 9V Carbon-zinc battery (6F22).
    • Optional: AC Adaptor (PSA series, sold separately).

    Size and Weight:

    • Width: 73 mm (2-7/8 inches).
    • Depth: 129 mm (5-1/8 inches).
    • Height: 59 mm (2-3/8 inches).
    • Weight (including battery): 380 g (14 oz).
    Add to cart
  • Sale!
    QuickView
    Wishlist
    Compare

    BOSS LS2 Line Selector Pedal

    Original price was: ₹16,291.00.Current price is: ₹14,500.00.
    • Compact line selection pedal for connecting and switching between multiple amplifiers and effects devices
    • Provides two line loops with Level control and six looping modes
    • Can supply power to several BOSS compact pedals when used with an AC adaptor
    • The ideal power supply and master switching unit for multiple effects setups
    • BOSS 5-year warranty
    Add to cart
  • QuickView
    Wishlist
    Compare

    BOSS MD-2 Mega Distortion

    10,654.00

    Input/Output Specifications:

    • Nominal Input Level: -20 dBu (standard line-level signal).
    • Input Impedance: 1 M ohm (ideal for high-impedance sources like electric guitars).
    • Nominal Output Level: -20 dBu.
    • Output Impedance: 1 k ohm (typical for line-level outputs).
    • Recommended Load Impedance: 10 k ohms or greater (for proper signal transfer).

    Bypass:

    • Buffered Bypass: Ensures the signal remains strong and clear when the effect is bypassed, preventing signal degradation.

    Controls:

    • GAIN BOOST Knob: Likely adds extra gain or distortion to the signal, enhancing the intensity of the effect.
    • DIST Knob: Adjusts the amount of distortion or overdrive applied to the signal.
    • TONE/BOTTOM Knob: Shifts the tonal character, probably adjusting treble or bass frequencies, allowing you to shape the sound to your preference.
    • LEVEL Knob: Controls the output volume of the effect.

    Indicator:

    • CHECK Indicator: Lights up when the battery is running low, alerting the user to check or replace the battery.

    Connectors:

    • INPUT Jack: 1/4-inch phone type (for connecting your instrument).
    • OUTPUT Jack: 1/4-inch phone type (to send the processed signal to an amplifier or the next device in the signal chain).
    • DC IN Jack: For connecting an external AC power adapter (PSA series, sold separately).

    Power Supply:

    • Battery:
      • Carbon-zinc 9V battery (6F22) or
      • Alkaline 9V battery (6LR61).
    • AC Adaptor: PSA series (sold separately).
    • Current Draw: 20 mA (very low current consumption, ideal for portable setups).
    • Expected Battery Life:
      • Carbon-zinc: Approx. 16 hours.
      • Alkaline: Approx. 30 hours (actual battery life may vary depending on usage).

    Accessories:

    • Included: Leaflet with safety and usage information, 9V Carbon-zinc battery (6F22).
    • Optional: AC Adapter (PSA series, sold separately).

    Size and Weight:

    • Width: 73 mm (2-7/8 inches).
    • Depth: 129 mm (5-1/8 inches).
    • Height: 59 mm (2-3/8 inches).
    • Weight (with battery): 395 g (14 oz).
    Add to cart
  • QuickView
    Wishlist
    Compare

    BOSS ML-2 Metal Core

    11,395.00

    Specifications

    • Nominal Input Level: -20 dBu
    • Input Impedance: 1 M ohm
    • Nominal Output Level: -20 dBu
    • Output Impedance: 1 k ohm
    • Recommended Load Impedance: 10 k ohms or greater
    • Bypass: Buffered bypass

    Controls

    • Pedal Switch
    • LEVEL Knob
    • LOW Knob
    • HIGH Knob
    • DIST Knob

    Indicator

    • CHECK Indicator: Serves as the battery check indicator.

    Connectors

    • INPUT Jack: 1/4-inch phone type
    • OUTPUT Jack: 1/4-inch phone type
    • AC Adaptor Jack: DC 9V

    Power Supply

    • Battery: Alkaline battery (9V, 6LR61)
    • AC Adaptor: PSA series (sold separately)

    Current Draw

    • 60 mA

    Expected Battery Life under Continuous Use

    • Alkaline: Approx. 5.5 hours
      (These figures may vary depending on actual conditions of use.)

    Accessories

    • Leaflet (“USING THE UNIT SAFELY,” “IMPORTANT NOTES,” and “Information”)
    • Battery: Alkaline battery (9V, 6LR61)

    Options (Sold Separately)

    • AC Adaptor: PSA series

    Size and Weight

    • Width: 73 mm (2-7/8 inches)
    • Depth: 129 mm (5-1/8 inches)
    • Height: 59 mm (2-3/8 inches)
    • Weight (Including Battery): 420 g (15 oz)
    Add to cart
  • QuickView
    Wishlist
    Compare

    BOSS MO-2 Multi Overtone

    14,939.00

    Input/Output Specifications:

    • Nominal Input Level: -20 dBu (a standard line-level signal)
    • Input Impedance: 1 M ohm (suitable for high-impedance sources like guitars)
    • Nominal Output Level: -20 dBu
    • Output Impedance: 1 k ohm (affects the interaction with connected equipment)
    • Recommended Load Impedance: 10 k ohms or greater (ensures proper signal transfer)

    Controls:

    • Pedal Switch: Engages or disengages the effect.
    • BALANCE Knob: Likely controls the balance between the wet (processed) and dry (unprocessed) signals.
    • TONE Knob: Adjusts the overall tone (high/low frequencies) of the effect.
    • DETUNE Knob: Likely adjusts the pitch or detuning effect, creating modulation or chorus effects.
    • MODE Knob: Changes the effect’s mode or type, altering how the effect behaves.

    Indicators:

    • CHECK Indicator: Serves as both an operational indicator and battery check light.

    Connectors:

    • INPUT Jack: For the instrument or signal source (likely 1/4-inch phone jack).
    • OUTPUT-A (MONO) Jack: Main output for mono or mixed output.
    • OUTPUT-B Jack: Additional output (for stereo or alternate routing).
    • AC Adaptor Jack (DC 9V): For connecting an external power supply (sold separately).

    Power Supply:

    • Battery: Alkaline 9V battery (6LR61).
    • AC Adaptor: PSA series (sold separately).
    • Current Draw: 60 mA.
    • Expected Battery Life: Approximately 3 hours (can vary based on usage).

    Accessories:

    • Included: Safety information leaflet, Alkaline 9V battery (6LR61).
    • Optional: AC Adapter (PSA series, sold separately).

    Dimensions and Weight:

    • Width: 73 mm (2-7/8 inches).
    • Depth: 129 mm (5-1/8 inches).
    • Height: 59 mm (2-3/8 inches).
    • Weight (with battery): 415 g (15 oz)
    Add to cart
  • QuickView
    Wishlist
    Compare

    BOSS MT-2 Metal Zone

    11,595.00

    Specifications

    • Nominal Input Level: -20 dBu
    • Input Impedance: 1 M ohm
    • Nominal Output Level: -20 dBu
    • Output Impedance: 1 k ohm
    • Recommended Load Impedance: 10 k ohms or greater
    • Bypass: Buffered bypass

    Controls

    • DIST Knob
    • EQUALIZER MIDDLE/MID FREQ Knob
    • EQUALIZER HIGH/LOW Knob
    • LEVEL Knob
    • Pedal Switch

    Indicator

    • CHECK Indicator: Used for indication of battery check.

    Connectors

    • INPUT Jack: 1/4-inch phone type
    • OUTPUT Jack: 1/4-inch phone type
    • DC IN Jack

    Power Supply

    • Battery: Carbon-zinc battery (9V, 6F22) or Alkaline battery (9V, 6LR61)
    • AC Adaptor: PSA series (sold separately)

    Current Draw

    • 30 mA

    Expected Battery Life under Continuous Use

    • Carbon: Approx. 12.5 hours
    • Alkaline: Approx. 23.5 hours
      (These figures may vary depending on actual conditions of use.)

    Accessories

    • Leaflet (“USING THE UNIT SAFELY,” “IMPORTANT NOTES,” and “Information”)
    • Battery: Carbon-zinc battery (9V, 6F22)

    Options (Sold Separately)

    • AC Adaptor: PSA series

    Size and Weight

    • Width: 73 mm (2-7/8 inches)
    • Depth: 129 mm (5-1/8 inches)
    • Height: 59 mm (2-3/8 inches)
    • Weight (Including Battery): 385 g (14 oz)
    Add to cart
  • QuickView
    Wishlist
    Compare

    BOSS MT-2W Metal Zone

    19,505.00

    Signal Specifications:

    • Nominal Input Level: -20 dBu
      • Standard for guitar-level input signals.
    • Input Impedance: 1 M ohm
      • High impedance, suitable for guitars and other high-impedance instruments.
    • Nominal Output Level: -20 dBu
      • Standard output level of the signal.
    • Output Impedance: 1 k ohm
      • Compatible with most amplifiers and pedals.
    • Recommended Load Impedance: 10 k ohms or greater
      • Ensures optimal performance with a wide range of amplifiers and effects chains.

    Bypass:

    • Buffered Bypass:
      • Ensures that the signal remains intact when the pedal is turned off, maintaining your guitar’s original tone.

    Controls:

    • Pedal Switch:
      • Turns the pedal on or off.
    • Mode Switch:
      • Allows you to switch between different distortion modes.
    • DIST Knob:
      • Adjusts the amount of distortion in the signal.
    • EQUALIZER MIDDLE/MID FREQ Knob:
      • Controls the middle frequencies (midrange) to shape the sound and enhance or cut specific frequencies.
    • EQUALIZER HIGH/LOW Knob:
      • Adjusts the high and low frequency ranges for more tonal control.
    • LEVEL Knob:
      • Controls the output volume of the effect.

    Power Supply:

    • Battery Options:
      • Alkaline 9V battery (6LR61).
      • Carbon-zinc 9V battery (6F22).
    • AC Adaptor:
      • PSA series (sold separately).
    • Current Draw:
      • 35 mA — Low power consumption for extended use.
    • Expected Battery Life:
      • Alkaline: Approx. 18 hours of continuous use.
      • Carbon-zinc: Approx. 7 hours of continuous use.

    Indicators:

    • CHECK Indicator:
      • Indicates when the battery is running low or when the pedal is engaged.

    Connectors:

    • INPUT Jack:
      • 1/4-inch phone type for connecting your instrument (guitar, bass, etc.).
    • OUTPUT Jack:
      • 1/4-inch phone type for sending the processed signal to your amplifier or effects chain.
    • DC IN Jack:
      • For connecting an external power supply (PSA series AC adapter).

    Accessories:

    • Included:
      • Leaflet with safety instructions and usage guidelines.
      • Alkaline 9V battery (6LR61).
    • Optional (sold separately):
      • AC Adaptor: PSA series.

    Size and Weight:

    • Width: 73 mm (2-7/8 inches).
    • Depth: 129 mm (5-1/8 inches).
    • Height: 59 mm (2-3/8 inches).
    • Weight (including battery): 440 g (1 lb).
    Add to cart
  • QuickView
    Wishlist
    Compare

    BOSS NS-2 Noise Suppressor

    11,395.00

    Input/Output Specifications:

    • Nominal Input Level: -20 dBu (standard line-level input).
    • Input Impedance: 1 M ohm (ideal for high-impedance sources like electric guitars).
    • Nominal Output Level: -20 dBu.
    • Output Impedance: 1 k ohm (standard for line-level outputs).
    • Recommended Load Impedance: 10 k ohms or greater (ensures proper interaction with other equipment).

    Bypass:

    • Buffered Bypass: Keeps the signal intact when the effect is turned off, ensuring that the dry signal does not degrade.

    Controls:

    • MODE Selector Switch: Selects between different processing modes (e.g., compression, limiting, or other dynamic control types).
    • DECAY Knob: Likely controls the decay time of the effect, affecting how quickly the processed signal fades or returns to the original level.
    • THRESHOLD Knob: Sets the level at which the effect (compression or limiting) is triggered. Signals above this threshold will be processed, while those below remain unaffected.
    • Pedal Switch: Engages or disengages the effect.

    Indicators:

    • CHECK/MUTE Indicator: Used for both battery check and muting status indication.
    • REDUCTION Indicator: Indicates the amount of signal reduction (compression or limiting) being applied.

    Connectors:

    • INPUT Jack: 1/4-inch phone type (for instrument or signal input).
    • OUTPUT Jack: 1/4-inch phone type (for sending the processed signal to an amplifier or next effect in the chain).
    • SEND Jack: 1/4-inch phone type (used in a send-return loop for connecting external devices).
    • RETURN Jack: 1/4-inch phone type (used to return the signal from an external device in a send-return loop).
    • DC IN Jack: For connecting an external AC power adapter (PSA series, sold separately).
    • 9V DC OUT Jack: Provides 9V power to other devices in the signal chain.

    Power Supply:

    • Battery:
      • Carbon-zinc 9V battery (6F22) or
      • Alkaline 9V battery (6LR61).
    • AC Adaptor: PSA series (sold separately).
    • Current Draw: 25 mA (low power consumption).
    • Expected Battery Life:
      • Carbon-zinc: Approx. 11 hours.
      • Alkaline: Approx. 24.5 hours (may vary depending on actual usage).

    Accessories:

    • Included: Safety and information leaflets, 9V Carbon-zinc battery (6F22).
    • Optional: AC Adapter (PSA series), Parallel DC Cord (PCS-20A, sold separately).

    Size and Weight:

    • Width: 73 mm (2-7/8 inches).
    • Depth: 129 mm (5-1/8 inches).
    • Height: 59 mm (2-3/8 inches).
    • Weight (with battery): 415 g (15 oz).
    Add to cart
1
9,500.00

    Cart

    Quantity
    9,500.00
    COMPARE PRODUCTS
