Name: Yamaha DBR15 Powered Loudspeaker
SKU: 4413
Availability: InStock

Yamaha DBR15 Powered Loudspeaker

		DBR15
General specifications
Speaker type		2-way, Bi-amp powered speaker, Bass-reflex type
Frequency range (-10dB)		50Hz – 20kHz
Nominal coverage	H	90°
Nominal coverage	V	60°
Components	LF	Diameter:15″ cone, Voice Coil:2.5″, Magnet:Ferrite
Components	HF	Diaphragm:1.4″, Type: 1″ throat compression driver, Magnet:Ferrite
Crossover		2.1kHz: FIR-X tuning™ (linear phase FIR filter)
Output power		Dynamic:1000 W (LF: 800 W, HF: 200 W) / Continuous: 465 W (LF: 400 W, HF: 65 W)
Maximum output level (1m; on axis)		132dB SPL
I/O connectors		INPUT1: Combo x1, INPUT2: Combo x 1 + RCA pin x 2 (Unbalanced), OUTPUT: XLR3-32 x 1 (CH1 Parallel Through or CH1+CH2 Mix)
Processors		D-CONTOUR: FOH/MAIN, MONITOR, OFF
Heat dissipation		Fan cooling, 4 speeds
Power requirements		100 V, 100-120V, 220-240 V, 110/127/220V (Brazil), 50/60Hz
Power consumption		74W(1/8 Power Consumption), 18W(Idle)
Cabinet material		Plastic
Finish		Black
Handle		Side x 2
Flying and mounting hardware		Bottom x 2, Rear x 1 (Fit for M8 x 15 mm eyebolts)
Pole socket		35mm (Bottom x 1)
Dimensions	W	455mm (17.9″)
	H	700mm (27.6″)
	D	378mm (14.9″)
Net weight		19.3 kg (42.6 lbs)
Accessories		BBS251, BCS251, BWS251-300, BWS251-400 (Optional Speaker bracket)

Spread the love

The DBR15 achieves best-in-class SPL of up to132dB and delivers the lowest frequency in its lineup. The DBR15 delivers outstanding performance for the main front-of-house sound for the live performance or DJ events that require highly prominent low and more power.
