Showing 337–348 of 1770 results

Sale!

Boss RC505 MKII Loop Station
Original price was: ₹80,332.00.Current price is: ₹72,000.00.
Standard Features

The industry-standard tabletop looper, updated and enhanced

Class-leading sound quality with 32-bit AD/DA and 32-bit floating-point processing

Five simultaneous stereo phrase tracks with dedicated controls and independent volume faders

Input FX and Track FX sections, each with four simultaneous effects and four quick-access banks

Customizable FX and Track buttons for each phrase track

Massive onboard effects selection with 49 Input FX types and 53 Track FX types, including new Harmony, Electric FX, and many others

New ultra-durable faders with longer throw for more precise adjustment

Newly added Mark Back function provides enhanced undo/redo flexibility while performing

Two XLR mic inputs with phantom power, two stereo line input pairs, and three stereo line output pairs

99 memories, each containing five phrase tracks, custom effects and playback settings, control assignments, and more

Synchronize your loops with over 200 onboard rhythm patterns and 16 drum kits

Deep MIDI control support

Two external control jacks, each with support for up to two footswitches or an expression pedal

USB for data backup, phrase import/export with BOSS Tone Studio, and pattern import with the RC Rhythm Converter
Add to cart
Sale!

BOSS RE-2 Space Echo
Original price was: ₹36,902.00.Current price is: ₹33,000.00.
Input/Output Specifications:

Nominal Input Level: -20 dBu (standard line-level input).

Maximum Input Level: +7 dBu (maximum acceptable signal level before distortion or clipping).

Input Impedance: 1 M ohm (high impedance, suitable for instruments like guitars or basses).

Nominal Output Level: -20 dBu (standard output level).

Maximum Output Level: +7 dBu (maximum acceptable output before clipping).

Output Impedance: 1 k ohm (standard for line-level outputs).

Recommended Load Impedance: 10 k ohms or greater (for proper signal transfer and compatibility).

Bypass:

Buffered Bypass: Ensures that the signal is preserved and not degraded when the pedal is turned off, allowing for better tone integrity.

Controls:

MODE Knob: Switch between different delay modes or effect types, potentially offering a variety of delay sounds (e.g., analog, digital, etc.).

REPEAT RATE Knob: Adjusts the speed or rate of the delay repetitions, affecting how fast the echo repeats occur.

WOW & FLUTTER Knob: Likely adds a modulation effect to the delay, simulating the pitch variation found in analog tape delays.

INTENSITY Knob: Controls the depth or strength of the delay effect, impacting how pronounced the echo is.

TONE Knob: Adjusts the tonal quality of the delayed sound, potentially controlling high or low-frequency emphasis.

ECHO Knob: Likely adjusts the level of the delay effect in the overall mix, balancing it with the dry signal.

REVERB Knob: Adds reverb to the signal, further enhancing the spatial effect of the sound.

CARRYOVER Switch: Likely controls whether the delay continues to sound after the pedal is bypassed, useful for creating smooth transitions in live performance.

Indicator:

CHECK Indicator: Lights up when the battery is low or when the pedal is in need of maintenance, ensuring you don’t run out of power unexpectedly.

Connectors:

INPUT A (MONO) and INPUT B Jack: 1/4-inch phone type jacks for connecting your instrument or audio source.

OUTPUT A (MONO) and OUTPUT B Jack: 1/4-inch phone type jacks for sending the processed signal to an amplifier or additional effects.

CTL/EXP Jack: 1/4-inch TRS (Tip-Ring-Sleeve) jack for connecting a footswitch or expression pedal (sold separately), allowing for additional control over the effects in real-time.

DC IN Jack: For connecting an external AC power adapter (PSA series, sold separately).

Power Supply:

Battery: Alkaline 9V battery (6LR61).

AC Adaptor: PSA series (sold separately).

Current Draw: 75 mA (moderate current consumption).

Expected Battery Life: Approx. 4.5 hours of continuous use with an alkaline battery (actual life may vary depending on usage conditions).

Accessories:

Included: Leaflet with safety and usage information, 9V alkaline battery (6LR61).

Optional: AC Adapter (PSA series), Footswitch (FS-5U), Dual Footswitch (FS-6, FS-7), Expression Pedal (FV-500H, FV-500L, EV-30, Roland EV-5).

Size and Weight:

Width: 73 mm (2-7/8 inches).

Depth: 129 mm (5-1/8 inches).

Height: 59 mm (2-3/8 inches).

Weight (with battery): 450 g (1 lb).
Add to cart

BOSS RT-2 Rotary Ensemble

Category	Details
Sample Rate	48 kHz
AD Conversion	24 bits + AF method (Adaptive Focus method – proprietary Roland & BOSS technology that improves signal-to-noise ratio for AD and DA converters)
DA Conversion	32 bits
Nominal Input Level	INPUT A (MONO), INPUT B: -20 dBu
Maximum Input Level	INPUT A (MONO), INPUT B: +7 dBu
Input Impedance	INPUT A (MONO), INPUT B: 1 MΩ
Nominal Output Level	OUTPUT A (MONO), OUTPUT B: -20 dBu
Maximum Output Level	OUTPUT A (MONO), OUTPUT B: +7 dBu
Output Impedance	OUTPUT A (MONO), OUTPUT B: 1 kΩ
Recommended Load Impedance	OUTPUT A (MONO), OUTPUT B: 10 kΩ or greater
Bypass	Buffered bypass
Controls	SLOW knob, FAST knob, DRIVE knob, LEVEL knob, MODE switch, Pedal switch, RISE/FALL TIME switch, DRIVE KNOB switch
Indicator	CHECK indicator (used for Tempo and battery status)
Virtual Rotor	Included
Connectors	INPUT A (MONO) jack, INPUT B jack, OUTPUT A (MONO) jack, OUTPUT B jack (¼-inch phone type), CTL/EXP jack (¼-inch TRS phone type), DC IN jack
Power Supply	Alkaline battery (9V, 6LR61 or 6LF22, commercially available) or AC adaptor (PSA series: sold separately)
Current Draw	115 mA
Expected Battery Life (Continuous Use)	Approx. 2.5 hours (with alkaline battery; may vary with use conditions)
Accessories	Leaflet (“USING THE UNIT SAFELY,” “IMPORTANT NOTES,” and “Information”), Dry battery (9V, 6LR61 or 6LF22)
Options (Sold Separately)	AC adaptor (PSA series), Footswitch (FS-5U), Dual footswitch (FS-6, FS-7), Expression pedal (FV-500H, FV-500L, EV-30, Roland EV-5)
Dimensions	Width: 73 mm (2-7/8 in), Depth: 129 mm (5-1/8 in), Height: 59 mm (2-3/8 in)
Weight	450 g (1 lb, including battery)

Add to cart

Sale!

BOSS RV-500 Reverb

BOSS RV-200 Reverb Pedal – Specifications

Audio Performance

Parameter	Specification
Sampling Frequency	96 kHz
AD/DA Conversion	32-bit
Internal Processing	32-bit floating point

Reverb Modes (12 Total)

ROOM	HALL	PLATE	SPRING	SHIMMER	FAST DECAY
EARLY REFLECTION	NON-LINEAR	SFX	DUAL	SRV	SPACE ECHO

Memory

Banks	Patches
99 banks × 2 (A/B)	198 total
99 banks × 3 (A/B/C)	297 total (when C bank is active)

Input/Output Specs

Parameter	Value
Nominal Input Level	-10 dBu
Maximum Input Level	+8 dBu
Input Impedance	1 MΩ
Nominal Output Level	-10 dBu
Maximum Output Level	+8 dBu
Output Impedance	2 kΩ
Recommended Load Impedance	20 kΩ or greater

Bypass Mode

Type
Buffered or True Bypass (via relays)

Controls

Footswitches & Buttons	Knobs
A switch, B switch, TAP/CTL switch	MODE knob
DOWN, UP, EXIT, EDIT buttons	TIME/VALUE, PRE-DELAY, E.LEVEL
	LOW knob, HIGH knob

Display

Type
Graphic LCD (128 x 64 dots, backlit)

Connectors

Type	Description
INPUT A/MONO, B	1/4-inch phone type
OUTPUT A/MONO, B	1/4-inch phone type
CTL 1, 2 / EXP	1/4-inch TRS phone type
USB COMPUTER	USB Type B (for updates/MIDI)
MIDI IN/OUT	1/8-inch TRS (standard MIDI TRS)
DC IN	For 9V power adapter (PSA Series)

Power

Type	Specification
Battery	Alkaline (AA, LR6) × 4
Current Draw	225 mA
Battery Life	Approx. 4.5 hours (alkaline, varies by use)
AC Adapter (optional)	PSA-S series

Accessories

Included	Optional
Owner’s Manual	AC Adapter: PSA-S Series
Leaflet “USING THE UNIT SAFELY”	Footswitches: FS-5U, FS-5L, FS-6, FS-7
4× AA Alkaline Batteries	Expression Pedals: FV-500H/L, EV-30, EV-5

Size & Weight

Dimension	Metric	Imperial
Width	170 mm	6-3/4 inches
Depth	138 mm	5-7/16 inches
Height	62 mm	2-1/2 inches
Weight	1.0 kg (with batteries)	2 lbs 4 oz

Add to cart

Sale!

BOSS RV-6 Reverb
Original price was: ₹19,921.00.Current price is: ₹18,100.00.
Reverb Modes:

HALL: Simulates the acoustics of a large hall.

PLATE: Emulates the classic sound of a plate reverb.

ROOM: Mimics the acoustics of a small room.

SPRING: A reverb type associated with spring-based reverb tanks, often found in vintage amps.

MODULATE: Adds modulation to the reverb, creating a richer, more dynamic sound.

+DELAY: Adds a delay effect combined with the reverb.

SHIMMER: Adds an ethereal, high-pitched shimmer to the reverb.

DYNAMIC: Adjusts the reverb intensity based on the input signal’s dynamics, offering a more responsive effect.

Input/Output Specifications:

Nominal Input Level: -20 dBu (standard line-level input).

Input Impedance: 1 M ohm (ideal for instruments like electric guitars).

Nominal Output Level: -20 dBu.

Output Impedance: 1 k ohm.

Recommended Load Impedance: 10 k ohms or greater (ensures the best interaction with other equipment).

Controls:

Pedal Switch: Turns the effect on or off.

E.LEVEL Knob: Controls the level (intensity) of the reverb effect.

TONE Knob: Adjusts the high/low frequencies of the reverb sound.

TIME Knob: Controls the decay time or how long the reverb lasts.

MODE Knob: Selects between the different reverb modes mentioned above.

Indicators:

CHECK Indicator: Serves as an operational status indicator and also shows the battery’s health.

Connectors:

INPUT-A (MONO) Jack: Primary input for a mono signal (likely for instruments like guitars).

INPUT-B Jack: Secondary input for stereo input or alternate routing.

OUTPUT-A (MONO) Jack: Main output for the processed signal.

OUTPUT-B Jack: Secondary output for stereo or alternative routing.

EXP Jack: For connecting an expression pedal to control parameters such as reverb depth or time in real-time.

AC Adaptor Jack (DC 9V): For connecting an external power supply (sold separately).

Power Supply:

Battery: Alkaline 9V battery (6LR61).

AC Adaptor: PSA series (sold separately).

Current Draw: 95 mA.

Expected Battery Life: Approximately 3 hours (varies with usage).

Accessories:

Included: Safety and information leaflets, Alkaline 9V battery.

Optional: AC Adapter (PSA series), Expression Pedal (BOSS FV-500H, FV-500L, Roland EV-5).

Dimensions and Weight:

Width: 73 mm (2-7/8 inches).

Depth: 129 mm (5-1/8 inches).

Height: 59 mm (2-3/8 inches).

Weight (with battery): 450 g (1 lb).
Add to cart
Sale!

BOSS SD-1W SUPER OverDrive
Original price was: ₹23,406.00.Current price is: ₹21,500.00.

SpecificationsNominal Input Level-20 dBuInput Impedance1 M ohmNominal Output Level-20 dBuOutput Impedance1 k ohmRecommended Load Impedance10 k ohms or greaterControlsPedal switch
Mode switch
LEVEL knob
TONE knob
DRIVE knobIndicatorCHECK indicator (Serves also as battery check indicator)ConnectorsINPUT jack
OUTPUT jack
DC IN jackPower SupplyAlkaline battery (9 V, 6LR61) or Carbon-zinc battery (9 V, 6F22)
AC adaptor (sold separately)Current Draw15 mAExpected battery life under continuous use (These figures will vary depending on the actual conditions of use.)Carbon: Approx. 25 hours
Alkaline: Approx. 42 hoursAccessoriesLeaflet (“USING THE UNIT SAFELY,” “IMPORTANT NOTE,” and “Information”)
Carbon-zinc battery (9 V, 6F22)Option (sold separately)AC adaptor (PSA series)Size and WeightWidth73 mm
2-7/8 inchesDepth129 mm
5-1/8 inchesHeight59 mm
2-3/8 inchesWeight430 g
1 lb

Add to cart
Sale!

BOSS SL-2 Slicer
Original price was: ₹22,047.00.Current price is: ₹19,394.00.
Specifications

Sample Rate:

48 kHz

AD Conversion:

24 bits + AF method (Adaptive Focus method)

This proprietary method from Roland & BOSS improves the signal-to-noise (SN) ratio of the AD and DA converters.

DA Conversion:

32 bits

Patterns:

88 patterns

Input and Output

Nominal Input Level:

INPUT A (MONO), INPUT B: -20 dBu

Maximum Input Level:

INPUT A (MONO), INPUT B: +7 dBu

Input Impedance:

INPUT A (MONO), INPUT B: 1 MΩ

Nominal Output Level:

OUTPUT A (MONO), OUTPUT B: -20 dBu

Maximum Output Level:

OUTPUT A (MONO), OUTPUT B: +7 dBu

Output Impedance:

OUTPUT A (MONO), OUTPUT B: 1 kΩ

Recommended Load Impedance:

OUTPUT A (MONO), OUTPUT B: 10 kΩ or greater

Bypass:

Buffered bypass

Controls

TYPE Knob:

Selects different types of effects.

VARIATION Knob:

Adjusts the variation of the effect.

ATTACK Knob:

Controls the attack of the effect.

DUTY Knob:

Adjusts the duty cycle of the effect.

TEMPO Knob:

Controls the tempo for time-based effects.

BALANCE Knob:

Adjusts the balance between the outputs.

Pedal Switch:

Activates or deactivates the effect.

Indicators

CHECK Indicator:

Used for indicating tempo and checking the battery.

Connectors

INPUT A (MONO) Jack, INPUT B Jack:

1/4-inch phone type

For instrument input.

OUTPUT A (MONO) Jack, OUTPUT B Jack:

1/4-inch phone type

For audio output.

CTL/EXP Jack:

1/4-inch TRS phone type

For control or expression pedal.

DC IN Jack:

For external power supply.

MIDI IN Jack:

Stereo miniature phone type

For MIDI input.

USB Port:

USB B

For connection to a computer or other devices.

Power Supply

Battery Options:

Alkaline: 9V, 6LR61 or 6LF22 (commercially available)

AC Adaptor:

PSA series (sold separately)

Current Draw:

95 mA

Expected Battery Life (under continuous use):

Alkaline: Approx. 2.5 hours

Note: These figures may vary depending on actual usage conditions.

Accessories

Included:

Leaflet (“USING THE UNIT SAFELY,” “IMPORTANT NOTES,” and “Information”)

Dry Battery (9V, 6LR61 or 6LF22)

Optional (sold separately):

AC Adaptor: PSA series

Footswitch: FS-5U

Dual Footswitch: FS-6, FS-7

Expression Pedal: FV-500H, FV-500L, EV-30, Roland EV-5

TRS/MIDI Connecting Cables: BMIDI-5-35, BMIDI-1-35, BMIDI-2-35, BCC-1-3535, BCC-2-3535

Size and Weight

Width:

73 mm (2-7/8 inches)

Depth:

129 mm (5-1/8 inches)

Height:

59 mm (2-3/8 inches)

Weight (including battery):

450 g (1 lb)
Add to cart
Sale!

BOSS ST-2 Power Stack
Original price was: ₹13,667.00.Current price is: ₹12,400.00.
Specifications

Nominal Input Level: -20 dBu

Input Impedance: 1 M ohm

Nominal Output Level: -20 dBu

Output Impedance: 1 k ohm

Recommended Load Impedance: 10 k ohms or greater

Bypass: Buffered bypass

Controls

SOUND Knob

TREBLE Knob

BASS Knob

LEVEL Knob

Pedal Switch

Indicator

CHECK Indicator: Used for indication of check battery.

Connectors

INPUT Jack: 1/4-inch phone type

OUTPUT Jack: 1/4-inch phone type

DC IN Jack

Power Supply

Battery: Alkaline battery (9V, 6LR61)

AC Adaptor: PSA series (sold separately)

Current Draw

65 mA

Expected Battery Life under Continuous Use

Alkaline: Approx. 5.5 hours
(These figures may vary depending on actual conditions of use.)

Accessories

Leaflet (“USING THE UNIT SAFELY,” “IMPORTANT NOTES,” and “Information”)

Battery: Alkaline battery (9V, 6LR61)

Options (Sold Separately)

AC Adaptor: PSA series

Size and Weight

Width: 73 mm (2-7/8 inches)

Depth: 129 mm (5-1/8 inches)

Height: 59 mm (2-3/8 inches)

Weight (Including Battery): 410 g (15 oz)
Add to cart
Sale!

BOSS SY-1 Synthesizer
Original price was: ₹27,234.00.Current price is: ₹25,200.00.
Input/Output Specifications:

Nominal Input Level: -20 dBu (a standard reference level for line-level inputs)

Input Impedance: 2.2 M ohms (a high impedance, suitable for guitars or basses)

Nominal Output Level: -20 dBu

Output Impedance: 1 k ohms (affects the interaction with downstream equipment like amplifiers)

Recommended Load Impedance: 10 k ohms or greater (ensures proper signal transfer and tone preservation)

Controls:

Pedal Switch: Activates or deactivates the effect.

GUITAR/BASS Switch: Likely switches between optimal settings for guitar or bass use.

TYPE Knob: Likely selects different types of effects or tones.

VARIATION Knob: Likely modifies the effect’s variation or intensity.

TONE Knob: Adjusts the high/low frequency balance.

DEPTH Knob: Controls the depth or intensity of the effect.

EFFECT Knob: Controls the overall effect level.

DIRECT Knob: May control the blend between dry (direct) and processed signal.

CHECK Indicator: Serves as both an operational check and a battery indicator.

Connectors:

INPUT: 1/4-inch phone jack.

OUTPUT: 1/4-inch phone jack.

SEND: 1/4-inch phone jack (for send effects loops).

RETURN: 1/4-inch phone jack (for returning effects loops).

EXP/CTL Jack: Stereo 1/4-inch jack for connecting an expression pedal or external control.

DC IN Jack: For connecting to a power supply (AC adapter).

Power Supply:

Battery: Alkaline 9V battery (6LR61).

AC Adapter: PSA series (sold separately).

Current Draw: 115 mA.

Expected Battery Life: Approximately 2 hours (may vary depending on usage conditions).

Accessories:

Included: Safety information leaflet, Alkaline 9V battery (6LR61).

Optional: AC Adapter (PSA series), Footswitch (FS-5U), Dual Footswitch (FS-6, FS-7), Expression Pedal (FV-500H, FV-500L, EV-30, Roland EV-5).

Dimensions and Weight:

Width: 73 mm (2-7/8 inches).

Depth: 129 mm (5-1/8 inches).

Height: 59 mm (2-3/8 inches).

Weight (with battery): 450 g (1 lb).
Add to cart

Sale!

BOSS SY-200 Synthesizer

BOSS SY-1 Guitar Synthesizer – Specifications

Category	Specification
Sampling Frequency	44.1 kHz
AD/DA Conversion	24-bit
Processing	32-bit floating point
Modes	12 (LEAD, PAD, STRING, BELL, ORGAN, BASS, DUAL, SWEEP, NOISE, SFX, SEQ, ARPEGGIO)
Memory	128
Nominal Input Level	-10 dBu
Maximum Input Level	+7 dBu
Input Impedance	2 MΩ (INPUT, RETURN)
Nominal Output Level	-10 dBu
Maximum Output Level	+7 dBu
Output Impedance	1 kΩ (OUTPUT, SEND)
Recommended Load	10 kΩ or greater
Bypass	Buffered bypass

Controls & Interface

Component	Details
Switches	ON/OFF, MEMORY/CTL 1
Knobs	TYPE, MEMORY, 1, 2, 3, D. LEVEL, E. LEVEL, VARIATION
Buttons	MENU, EXIT
Display	Graphic LCD (132 × 32 dots, backlit)

Connectivity

Connector	Type
INPUT / OUTPUT / SEND / RETURN	1/4” phone type
CTL 2, 3 / EXP	1/4” TRS phone type
MIDI IN / OUT	Stereo mini phone type
USB	USB micro-B (for updates only)
DC IN	For PSA-series AC adapter

Power

Power Source	Alkaline battery (AA, LR6) x 3 or AC adaptor (sold separately)
Current Draw	230 mA
Battery Life	Approx. 5 hours (with alkaline batteries)

Included Accessories

Items
Leaflet: “USING THE UNIT SAFELY”
Leaflet: “To obtain the Owner’s Manual”
Alkaline battery (AA, LR6) x 3
Rubber foot x 4

Optional Accessories (Sold Separately)

Accessory Type	Models
AC Adaptor	PSA-S series
Footswitches	FS-5U, FS-6, FS-7
Expression Pedals	FV-500H, FV-500L, EV-30, Roland EV-5
MIDI/TRS Cables	BMIDI-5-35, BMIDI-1-35, BMIDI-2-35, BCC-1-3535, BCC-2-3535

Size & Weight

Dimension	Metric	Imperial
Width	101 mm	4 inches
Depth	138 mm	5-7/16 inches
Height	63 mm	2-1/2 inches
Height (with rubber feet)	65 mm	2-9/16 inches
Weight	630 g	1 lb 7 oz
Weight (with battery)	700 g	1 lb 9 oz

Add to cart

Sale!

BOSS TR-2 Tremolo
Original price was: ₹13,560.00.Current price is: ₹12,000.00.
Input/Output Specifications:

Nominal Input Level: -20 dBu (standard line-level signal).

Input Impedance: 1 M ohm (suitable for use with high-impedance sources like electric guitars).

Nominal Output Level: -20 dBu.

Output Impedance: 1 k ohm (ideal for connecting to amplifiers or other effects units).

Recommended Load Impedance: 10 k ohms or greater (ensures proper performance and signal transfer).

Bypass:

Buffered Bypass: Keeps the signal intact when the pedal is off, ensuring the signal doesn’t degrade through the pedal when bypassed.

Controls:

DEPTH Knob: Controls the intensity or depth of the modulation effect (such as the amount of variation in pitch or tone).

RATE Knob: Adjusts the speed or rate at which the modulation effect occurs (e.g., speed of chorus or phaser).

WAVE Knob: Likely adjusts the waveform of the modulation effect (e.g., from sine to square wave, which changes the nature of the modulation).

Indicator:

CHECK Indicator: Displays the status of the battery, helping users check if it needs replacing.

Connectors:

INPUT Jack: 1/4-inch phone type (for instrument input like guitar or bass).

OUTPUT Jack: 1/4-inch phone type (for sending the effect signal to an amplifier or next effect in the chain).

DC IN Jack: For connecting an external AC power adapter (PSA series, sold separately).

Power Supply:

Battery:

Carbon-zinc 9V battery (6F22) or

Alkaline 9V battery (6LR61).

AC Adaptor: PSA series (sold separately).

Current Draw: 25 mA (low current consumption).

Expected Battery Life:

Carbon-zinc: Approx. 12 hours.

Alkaline: Approx. 28 hours (actual battery life may vary based on usage).

Accessories:

Included: Leaflet with safety and usage information, 9V Carbon-zinc battery (6F22).

Optional: AC Adapter (PSA series, sold separately).

Size and Weight:

Width: 73 mm (2-7/8 inches).

Depth: 129 mm (5-1/8 inches).

Height: 59 mm (2-3/8 inches).

Weight (with battery): 385 g (14 oz).
Add to cart
Sale!

BOSS TU-3 Chromatic Tuner
Original price was: ₹13,590.00.Current price is: ₹12,200.00.
Tuning Features:

Tuning Range: From C0 (16.35 Hz) to C8 (4186 Hz), covering the entire range of most instruments.

Reference Pitch (A4): Adjustable from 436 Hz to 445 Hz in 1 Hz steps, allowing you to fine-tune the reference pitch to suit your tuning needs.

Tuning Accuracy: +/- 1 cent, providing highly precise tuning that ensures accurate intonation.

Modes:

Chromatic Mode: A mode that allows tuning to all notes, offering maximum flexibility for all instruments.

Chromatic Flat x2 Mode: A chromatic tuning mode with an additional flat tuning range.

Guitar Mode: Preconfigured for standard guitar tuning.

Guitar Flat x2 Mode: A mode allowing for flat tunings on guitar (e.g., drop tunings).

Bass Mode: Configured for bass guitars, including low-end tuning.

Bass Flat x3 Mode: A bass-specific mode with additional flat tunings.

Display Modes:

Cent Mode: Displays the pitch in cents for precise tuning adjustments.

Stream Mode: Likely shows a dynamic, stream-like visualization of the tuning process, helping the user easily see whether they’re sharp or flat.

Input/Output:

Nominal Input Level: -20 dBu, suitable for most line-level signals.

Input Impedance: 1 M ohm, ideal for high-impedance instruments like electric guitars or basses.

Nominal Output Level: -20 dBu.

Output Impedance: 1 k ohm.

Recommended Load Impedance: 10 k ohms or greater, ensuring compatibility with most amplifiers or audio equipment.

Bypass:

Buffered Bypass: Ensures that the signal remains strong and unaffected when the tuner is bypassed, preventing signal degradation.

Controls:

Pedal Switch: Used to toggle the tuner on or off.

MODE Button: Switch between different tuning modes (chromatic, guitar, bass, etc.).

STREAM/CENT Button: Switch between display modes (Stream mode or Cent mode).

Power Supply:

Battery:

Carbon-zinc 9V battery (6F22) or

Alkaline 9V battery (6LR61).

AC Adaptor: PSA series (sold separately).

Current Draw:

20 mA under normal use.

80 mA when High Brightness mode is on (likely for better visibility in bright environments).

Expected Battery Life:

Carbon-zinc: Approx. 5 hours.

Alkaline: Approx. 21 hours.

Connectors:

INPUT Jack: 1/4-inch phone type for connecting your instrument.

OUTPUT Jack: 1/4-inch phone type for sending the signal to an amplifier or next device.

BYPASS Jack: Likely for external control of bypass (for example, using a footswitch).

DC IN Jack: For connecting an external AC power adapter (PSA series).

DC OUT Jack: Likely allows for chaining multiple pedals or devices together.

Accessories:

Included: Leaflet with safety and usage information, 9V Carbon-zinc battery (6F22).

Optional: AC Adapter (PSA series), Parallel DC cord (PCS-20A, DC Plug x8).

Size and Weight:

Width: 73 mm (2-7/8 inches).

Depth: 129 mm (5-1/8 inches).

Height: 59 mm (2-3/8 inches).

Weight (including battery): 390 g (14 oz).
Add to cart

Archives: Shop

Boss RC505 MKII Loop Station

Standard Features

BOSS RE-2 Space Echo

Input/Output Specifications:

Bypass:

Controls:

Indicator:

Connectors:

Power Supply:

Accessories:

Size and Weight:

BOSS RT-2 Rotary Ensemble

BOSS RV-500 Reverb

Audio Performance

Reverb Modes (12 Total)

Memory

Input/Output Specs
