BOSS RC-202 Loop Station

Nominal Input Level:

• INPUT MIC (variable): -40 dBu (typ.), -10 dBu (max)
• INPUT INST: -10 dBu
• AUX IN: -20 dBu

Input Impedance:

• INPUT MIC: 4 k ohms
• INPUT INST: 1 M ohm
• AUX IN: 22 k ohms

Nominal Output Level:

• OUTPUT: -10 dBu

Output Impedance:

• OUTPUT: 1 k ohm

Recommended Load Impedance:

• OUTPUT: 10 k ohms or greater

Recording/Playback:

• Maximum Recording Time: Approx. 3 hours (stereo)
• Maximum Phrase Memory: 8 Memory x 8 Bank
• Number of Tracks: 2
• Data Format: WAV (44.1 kHz, 16-bit linear, stereo)

Effect Type (INPUT FX / TRACK FX):

• LPF
• BPF
• HPF
• PHASER
• FLANGER
• SYNTH
• LO-FI
• RING MODULATOR
• GUITAR TO BASS
• SLOW GEAR
• TRANSPOSE
• PITCH SHIFT
• ROBOT
• VOCAL DIST
• VOCODER
• NATURAL COMP
• HARD COMP
• NATURAL LIM
• HARD LIM
• PHONE VOX
• EQ
• LOW ISOLATOR
• MID ISOLATOR
• HIGH ISOLATOR
• OCTAVE
• AUTO PAN
• MANUAL PAN
• TREMOLO
• SLICER
• DELAY
• PANNING DELAY
• TAPE ECHO
• GRANULAR DELAY
• ROLL
• CHORUS
• REVERB
• BEAT REPEAT *1
• BEAT SHIFT *1
• BEAT SCATTER *1
• VINYL FLICK *1

*1 TRACK FX only

Effect Type (MASTER FX):

• COMP
• REVERB

Rhythm Type:

• 17 rhythms

Display:

• 7 segments, 3 characters (LED)

USB:

• Mass Storage Class Audio/MIDI

Connectors:

• INPUT MIC jack: XLR type (balanced, phantom power: DC 48 V, 10 mA Max)
• INPUT INST (L/MONO, R) jacks: 1/4-inch phone type
• AUX IN jack: Stereo miniature phone type
• Phones jack: Stereo miniature phone type
• OUTPUT (L/MONO, R) jacks: 1/4-inch phone type
• CTL 1, 2/EXP jack: 1/4-inch TRS phone type
• USB port: USB B Type
• MIDI (IN, OUT) connectors
• DC IN jack

Power Supply:

• AC adaptor
• Current Draw: 440 mA

Accessories:

• AC adaptor
• Owner’s manual
• Leaflet “USING THE UNIT SAFELY”

Options (sold separately):

• Footswitch: FS-5U, FS-6, FS-7
• Expression pedal: Roland EV-5, FV-500L, FV-500H

Size and Weight:

• Width: 239 mm (9-7/16 inches)
• Depth: 175 mm (6-15/16 inches)
• Height: 55 mm (2-3/16 inches)
• Weight (excluding AC Adaptor): 0.95 kg (2 lbs. 2 oz.)
